ProQual Level 3 Diploma in Engineering Surveying

Uncategorized
Wishlist Share

About Course

The online learning companion to DB College’s five-day ProQual Level 3 Diploma in Engineering Surveying. It follows the classroom and field programme day by day, so you can study before each day and revise after it.

You cover all five units: health, safety and survey maths (Unit A), levelling (Unit B), the total station (Unit C), GNSS (Unit D) and setting out (Unit E). Each lesson links to the assessment criteria and evidence codes for your portfolio, with worked examples, diagrams and quick checks. A quiz closes each day, and a final knowledge check covers the whole qualification.

The Learner Practical Handout Pack is included as a download. It holds the field tasks, booking sheets and sign-off sheets you complete with your assessor.

Show More

What Will You Learn?

  • Understand the health and safety law that applies to survey work
  • Solve right-angle triangles, bearings, distances and coordinate conversions
  • Carry out a two-peg test and book and reduce levels by rise and fall and HPC
  • Set up a total station, observe traverse rounds, apply atmospheric corrections and run a resection
  • Compute a traverse with the Bowditch method
  • Use network RTK GNSS and know when not to use it
  • Work with National Grid and local grid coordinates, drawings and data formats
  • Set out by coordinate, radial and offset methods, set profile boards and carry out OGL surveys

Course Content

Start here
What the qualification is, how the five days run, and how your work is assessed.

  • Welcome — how this course works
  • How you will be assessed

Day 1 — Unit A: Health, safety & maths foundations
Unit A (L/615/5308). Health and safety on survey work, the maths every surveyor uses, and how control networks are set up. AC 1.1, 2.1, 2.2, 2.5, 4.1, 4.3.

Day 2 — Unit B: Levelling
Unit B (R/615/5309). Sources of error, the two-peg test, types of level, and booking and reducing levels. AC 1.1, 1.2, 2.1, 4.1, 4.2.

Day 3 — Unit C: Total station
Unit C (J/615/5310). Observing angles and distances, atmospheric corrections, equipment care, traverse, resection, Bowditch computation and data output. AC 1.1, 1.2, 1.4, 1.5, 2.2, 2.3, 3.1, 4.1, 4.3.

Day 4 — Unit D: GNSS & Unit E: Setting out foundations
Unit D (L/615/5311) — static and network RTK GNSS and its limits. Unit E (R/615/5312) — coordinate systems, drawings and data formats. D AC 2.2, 3.2 · E AC 2.2, 2.4.

Day 5 — Unit E: Setting out in the field
Unit E (R/615/5312). Choosing equipment, uploading data, setting out methods, profile boards, tolerances, OGL and as-built surveys. AC 3.1, 3.3, 3.4, 3.5, 3.6, 4.1.

Portfolio completion & final knowledge check
Check every one of the 30 assessment criteria is evidenced, then sit the final knowledge check.
